Stainless Steel Automatic Drinker with Float 2.5L (ABD10) – SS304 Float Valve Waterer

Stainless Steel Automatic Float Waterer, 2.5L

The Stainless Steel Automatic Drinker is a self-filling water bowl that keeps fresh water available to your animals with no daily bucket filling. Made from corrosion-resistant SS304 stainless steel, it connects to your water supply and uses a float valve to refill itself as the animals drink, keeping the bowl topped up to a set level. It suits mains pressure or gravity feed, which makes it a versatile, hard-wearing drinker for horses, cattle, goats, sheep, poultry and other livestock.

How the Float Valve Works

The drinker works like a cistern. As animals drink and the water level drops, the float lowers and opens the valve to let fresh water in; once the bowl refills to the set level, the float rises and closes the valve. This keeps clean, fresh water available at all times without overflowing, and the float mechanism is adjustable so you can set the water level to suit. Because it works on mains or gravity feed, it fits a wide range of setups.

Built Tough in SS304 Stainless Steel

SS304 stainless is corrosion-resistant and hard-wearing, so this drinker stands up to paddock, yard and pen conditions far better than plastic. A hinged cover protects the float assembly from being fouled or knocked by the animals, and the bowl slopes from back to front, which gives animals easy access to drink and makes the bowl simpler to clean out.

Easy to Install and Clean

The drinker is wall-mountable (bolts not included) and connects via a brass male garden-hose-type fitting, so it is straightforward to plumb in. A drainage bung in the bowl lets you drain it quickly to clean it out and keep the water fresh, and the front-sloping design means there are no awkward corners to scrub.

Key Features & Benefits

• Automatic self-filling drinker in corrosion-resistant SS304 stainless steel
• Fills automatically according to the float level
• Adjustable float mechanism to set the water level
• Suits mains pressure or gravity feed
• Hinged cover protects the float assembly
• Drainage bung and front-sloping bowl for easy cleaning
• Wall-mountable with a brass hose-type fitting
• Approx. 2.5L capacity

Product Details

• Product: Stainless Steel Automatic Drinker with Float
• Model: ABD10
• Capacity: Approx. 2.5 litres
• Material: SS304 stainless steel
• Feed: Mains pressure or gravity
• Fitting: Brass male garden-hose-type
• Features: Adjustable float, hinged cover, drainage bung, wall-mountable (bolts not included)
• Suitable for: Horses, cattle, goats, sheep, poultry and other livestock

How to Use

Mount the drinker securely to a wall or post at a suitable height for your animals (bolts not included), and connect it to your water supply via the brass hose-type fitting, using either mains pressure or a gravity feed. Adjust the float so the bowl fills to the level you want. Check it regularly to confirm it is refilling correctly and the water is clean, and use the drainage bung to empty and clean the bowl as needed. Position it where animals can reach it easily but are less likely to soil it, and protect the supply line from damage.

Frequently Asked Questions

How does an automatic float drinker work?
As animals drink and the water level drops, the float lowers and opens the valve to let fresh water in. When the bowl refills to the set level, the float rises and shuts the valve, keeping the water topped up automatically.

Does it run on mains or gravity?
It suits both. You can connect it to mains pressure or run it from a gravity-fed water supply.

What is it made from?
It is made from SS304 stainless steel, which is corrosion-resistant and hard-wearing for outdoor livestock use.

What size is it?
It has an approximate 2.5 litre capacity, and being automatic, it refills itself, so the effective supply depends on your water connection.

How do I clean it?
It has a drainage bung so you can empty the bowl quickly, and the front-sloping shape makes it easy to wipe out and keep the water fresh.

Where can I buy a stainless steel automatic drinker in Australia?
It is available online from BPG Supplies, with shipping across Australia and local pickup in Bonnyrigg, NSW.
